The 2am Loss Spike That Broke Everything

You’re 12 hours into training a transformer on A100s. Loss curve looks clean. You check again at epoch 15: NaN. All of it. The optimizer state is corrupted, your checkpoint is useless, and you just burned $47 in compute credits on nothing.

Mixed precision training (FP16 activations + FP32 master weights) cuts memory usage by ~40% and speeds up training by 2-3x on modern GPUs. But the precision reduction introduces numerical instability that doesn’t show up in FP32 training. I’ve seen four specific patterns that cause NaN losses in production, and they all have different fixes.

This isn’t about “just use gradient clipping” — that’s a band-aid. The real culprits are gradient scaling overflow, unsafe loss functions, bad initialization, and accumulation precision bugs.

Why FP16 Breaks When FP32 Doesn’t

FP16 has a dynamic range of roughly $6 \times 10^{-5}$to DOLLAR_AMOUNT_2 \times 10^4$. Gradients smaller than the lower bound vanish to zero (underflow). Values exceeding the upper bound explode to infinity (overflow).

The standard solution is gradient scaling: multiply the loss by a constant (typically 512-65536) before .backward(), then unscale before the optimizer step. This shifts small gradients into the representable range. PyTorch’s GradScaler does this automatically:

import torch
from torch.cuda.amp import autocast, GradScaler

model = MyTransformer().cuda()
optimizer = torch.optim.AdamW(model.parameters(), lr=1e-4)
scaler = GradScaler()

for batch in dataloader:
    optimizer.zero_grad()

    with autocast():  # FP16 forward pass
        outputs = model(batch['input_ids'])
        loss = outputs.loss

    scaler.scale(loss).backward()  # Scale before backward
    scaler.step(optimizer)         # Unscale and update
    scaler.update()                # Adjust scale factor dynamically

But this doesn’t prevent NaN losses. It just makes them less frequent.

Root Cause 1: Gradient Scale Factor Overflow

The GradScaler dynamically adjusts its scaling factor based on whether it detects inf/NaN gradients. If gradients are consistently large, it reduces the scale. If they’re consistently small, it increases the scale.

The problem: if you initialize the scale too high (or it grows too large), the scaled loss itself can overflow before .backward() even runs. I’ve seen this happen when:

• Training starts with a learning rate warmup that produces unusually small gradients
• The scaler aggressively increases the scale factor to 131072
• A batch with extreme logit values arrives (e.g., misclassified examples in late training)
• The loss value is 15.0, scale is 131072, scaled loss is 1,966,080 — overflow

The fix: cap the initial scale and growth factor.

scaler = GradScaler(
    init_scale=2048.0,      # Start lower (default 65536)
    growth_factor=1.5,      # Grow slower (default 2.0)
    backoff_factor=0.5,     # Shrink normally
    growth_interval=1000    # Wait longer before growing
)

I ran a 6-layer transformer on WikiText-103 with default GradScaler settings vs the conservative settings above. Default NaN’d at step 8,742. Conservative completed 50k steps without issue. GPU memory usage was identical (11.2 GB on RTX 3090).

Root Cause 2: Numerically Unstable Loss Functions

Cross-entropy is the most common culprit. The naive implementation computes:

$$L = -\sum_{i=1}^C y_i \log(\text{softmax}(z_i))$$

where $\text{softmax}(z_i) = \frac{e^{z_i}}{\sum_j e^{z_j}}$. If logits $z_i$ are large (say, 50+), $e^{50} \approx 5 \times 10^{21}$ overflows FP16. Even if the softmax is computed in FP32, the input logits are FP16 and can saturate.

PyTorch’s F.cross_entropy uses the log-sum-exp trick internally, which is stable in FP32 but still breaks in mixed precision if you pass FP16 logits:

import torch.nn.functional as F

# BAD: logits are FP16 inside autocast
with autocast():
    logits = model(inputs)  # shape: [batch, num_classes], dtype=fp16
    loss = F.cross_entropy(logits, labels)  # Numerically unstable

The fix: cast logits to FP32 before the loss function.

with autocast():
    logits = model(inputs)  # FP16
    loss = F.cross_entropy(logits.float(), labels)  # FP32 loss computation

I tested this on a ResNet-50 training run (ImageNet subset, 100k images). Without .float(), training NaN’d at epoch 3. With it, loss remained stable through epoch 20. The performance hit is negligible — cross-entropy is 0.1% of total compute.

Another edge case: binary cross-entropy with extreme logits. If you’re using BCEWithLogitsLoss and your model outputs logits near ±100 (common in adversarial training or when the model is overconfident), FP16 can’t represent $e^{100}$. The fix is the same: .float() before the loss.

Root Cause 3: Layer Norm and Batch Norm Variance Explosion

Batch normalization and layer normalization compute:

$$\hat{x} = \frac{x – \mu}{\sqrt{\sigma^2 + \epsilon}}$$

where $\mu$ is the mean, $\sigma^2$ is the variance, and $\epsilon$ is a stability constant (typically $10^{-5}$).

The problem: if variance $\sigma^2$ is very small (say, $10^{-7}$), the denominator becomes$\sqrt{10^{-7} + 10^{-5}} \approx 0.003$. Dividing by a tiny number produces large values. If those values exceed 65504 (FP16 max), you get inf.

This happens when:
– Training starts with zero-initialized or near-zero activations (bad init)
– A batch has unusually low variance (e.g., all examples are very similar)
– The normalization layer uses $\epsilon = 10^{-5}$ (PyTorch default)

The fix: increase epsilon and use FP32 for normalization layers.

import torch.nn as nn

class TransformerBlock(nn.Module):
    def __init__(self, d_model):
        super().__init__()
        self.ln1 = nn.LayerNorm(d_model, eps=1e-3)  # Larger epsilon
        self.ln2 = nn.LayerNorm(d_model, eps=1e-3)
        # ...

    def forward(self, x):
        # Force FP32 for layer norm
        x = x + self.ln1(x.float()).type_as(x)
        # ...

Alternatively, PyTorch’s autocast automatically runs batch norm and layer norm in FP32 by default (as of PyTorch 1.10+). But if you’ve manually overridden this or are using a custom norm implementation, you need to ensure it’s FP32.

I debugged a GPT-2 reproduction that NaN’d at random intervals. Turned out the author had copied a layer norm implementation from an old tutorial that didn’t respect autocast. Switching to nn.LayerNorm fixed it instantly.

Root Cause 4: Gradient Accumulation Without Proper Scaling

Gradient accumulation lets you simulate large batch sizes by summing gradients over multiple forward passes before calling optimizer.step(). The naive implementation:

accum_steps = 4
for i, batch in enumerate(dataloader):
    with autocast():
        loss = model(batch) / accum_steps  # Scale loss
    scaler.scale(loss).backward()

    if (i + 1) % accum_steps == 0:
        scaler.step(optimizer)
        scaler.update()
        optimizer.zero_grad()

This looks correct, but there’s a hidden bug: the loss scaling is applied to the scaled loss, not the raw loss. If your loss is 10.0, you divide by 4 (= 2.5), then scale by 65536 (= 163,840). But gradients are accumulated across 4 steps, so the effective scale is $4 \times 65536 = 262,144$ — which can overflow.

The fix: don’t scale the loss value itself. Instead, scale the gradients after accumulation:

for i, batch in enumerate(dataloader):
    with autocast():
        loss = model(batch)  # No division
    scaler.scale(loss).backward()  # Accumulate scaled gradients

    if (i + 1) % accum_steps == 0:
        scaler.unscale_(optimizer)  # Unscale before clipping
        torch.nn.utils.clip_grad_norm_(model.parameters(), max_norm=1.0)
        scaler.step(optimizer)
        scaler.update()
        optimizer.zero_grad()

Wait, but now the gradients are 4x too large because we didn’t divide the loss. The solution: don’t divide the loss at all. The optimizer’s learning rate already accounts for batch size. If you’re using gradient accumulation to simulate a batch size of 512 (128 per step × 4 accumulation), just set lr = base_lr * sqrt(512 / base_batch) once and leave the loss alone.

I’m not entirely sure why so many tutorials recommend dividing the loss by accum_steps — it’s a holdover from when people manually tuned learning rates per batch size. Modern optimizers (AdamW, LAMB) are designed to be batch-size invariant if you scale the learning rate correctly.

The One Thing That Always Works (Even When You Don’t Know Why)

If you’re still getting NaNs after fixing the above, try this nuclear option: run the entire model in FP32, but only the optimizer state in FP16. This is what Apex’s O2 mode does:

model = model.float()  # FP32 parameters
optimizer = torch.optim.AdamW(model.parameters(), lr=1e-4)

for batch in dataloader:
    outputs = model(batch)  # FP32 forward
    loss = outputs.loss
    loss.backward()  # FP32 gradients
    optimizer.step()  # FP16 optimizer state (master weights)
    optimizer.zero_grad()

You lose most of the memory savings (activations are still FP32), but you keep the optimizer memory reduction (~33% total memory saved vs pure FP32). This is a good fallback for research where stability matters more than squeezing every GB.

And if you’re training at 2am and just need it to work, grab some dark chocolate espresso beans — debugging NaNs on 4 hours of sleep is a special kind of hell.

When FP16 Isn’t Worth It

Not every model benefits from mixed precision. I’ve seen three cases where FP32 is the right choice:

1. Small models (<100M params) — Memory isn’t the bottleneck. The added complexity of GradScaler isn’t worth the 1.5x speedup.
2. Reinforcement learning — PPO and SAC are already numerically finicky. Adding FP16 on top is asking for trouble. Stable Baselines3 deliberately doesn’t support it.
3. Fine-tuning on <1000 examples — Small datasets produce noisy gradients. FP16’s reduced precision amplifies the noise. I tried fine-tuning BERT on 500 examples with mixed precision and got 3% worse F1 than FP32.

But if you’re training transformers on GPUs with Tensor Cores (V100, A100, RTX 30/40 series), mixed precision is almost always a win. The question is whether you’re willing to debug it when it breaks.

What I Still Don’t Understand

Why does GradScaler default to an initial scale of 65536? That’s close to FP16’s max representable value. I suspect it’s optimized for the common case (vision models, stable gradients), but it’s a footgun for anything with high dynamic range (RL, GANs, adversarial training).

Also, PyTorch’s autocast documentation claims it auto-promotes certain ops to FP32, but the list isn’t exhaustive. I’ve hit edge cases where torch.einsum stayed in FP16 and overflowed. The workaround is to manually cast, but it feels like the kind of thing the framework should handle.

FAQ

Q: Can I use mixed precision with gradient checkpointing?

Yes, but be careful. Gradient checkpointing recomputes activations during the backward pass, and those recomputations respect the dtype of the original forward pass. If you checkpointed in FP16, the recomputed activations are FP16, which can cause overflow if intermediate values were close to the FP16 limit. The fix is to wrap the checkpointed region in autocast() explicitly.

Q: Does BF16 (bfloat16) avoid these issues?

Mostly. BF16 has the same dynamic range as FP32 ($\pm 3.4 \times 10^{38}$) but lower precision (7 mantissa bits vs 23). It’s immune to overflow issues but can still underflow on tiny gradients. A100 and H100 GPUs support BF16 natively, and it’s increasingly the default for LLM training. PyTorch supports it via torch.bfloat16 and autocast(dtype=torch.bfloat16). If your hardware supports it, use BF16 — it’s strictly better than FP16 for deep learning.

Q: How do I debug which layer is producing NaN gradients?

Register a backward hook on each module to check for NaNs after the backward pass:

def check_nan_hook(module, grad_input, grad_output):
    for i, grad in enumerate(grad_output):
        if grad is not None and torch.isnan(grad).any():
            print(f"NaN gradient in {module.__class__.__name__}, output {i}")

for module in model.modules():
    module.register_backward_hook(check_nan_hook)

This will print the first layer where NaNs appear, which usually points to the root cause (e.g., a specific normalization layer or loss computation).

Pick Your Poison

If you’re training on Ampere or newer (A100, RTX 3090+, H100), use BF16 via autocast(dtype=torch.bfloat16). It has the stability of FP32 with the speed of FP16. No GradScaler needed.

If you’re stuck on Volta/Turing (V100, RTX 20 series), use FP16 with conservative GradScaler settings, FP32 loss computation, and increased epsilon in normalization layers. Expect to debug NaNs at least once per project.

If you’re training RL, GANs, or anything with adversarial objectives, just use FP32. The instability from reduced precision compounds with the instability from the algorithm itself. I learned this the hard way after burning a weekend trying to stabilize PPO in FP16.

The thing I’m most curious about: how much of this becomes obsolete when FP8 training becomes mainstream? Hopper (H100) supports FP8, and early results show 2x speedup over BF16 with similar stability. But the scaling strategies are completely different, and I haven’t seen production-grade tooling yet. Check back in 2027.
