SAM vs FastSAM vs SAM 2: Inference Speed Benchmark

FastSAM is 15x faster than SAM on my RTX 3090, but it misses 22% of fine details

I spent the weekend running 500 images through SAM, SAM 2, and FastSAM to settle the speed-vs-quality debate once and for all. The headline number everyone quotes—”FastSAM is 50x faster!”—turns out to be misleading. On real-world images with mixed object sizes, the gap shrinks dramatically, and the quality trade-off is harder than the papers suggest.

Here’s what actually happened when I benchmarked all three models on identical hardware with consistent preprocessing. The results surprised me, especially around memory usage.

The models: architecture differences that explain the speed gap

SAM (Segment Anything Model, Kirillov et al., 2023) uses a massive ViT-H image encoder with 632M parameters. The encoder runs once per image, producing a 256×64×64 embedding. Then for each prompt (point, box, or mask), a lightweight decoder generates the segmentation in ~50ms. Total first-frame time? Around 3-4 seconds on GPU.

FastSAM takes a completely different approach—it’s actually YOLOv8-seg under the hood. The “Fast” comes from replacing the ViT encoder with a CNN backbone (CSPDarknet). No separate encoder-decoder. Just one forward pass: image in, instance masks out. The authors claim this drops inference from seconds to ~30ms.

SAM 2 (released mid-2024) is architecturally similar to SAM but adds a memory attention mechanism for video. For single-image tasks, it’s basically SAM with a slightly optimized encoder and better batching. The memory mechanism is overkill for static images, but the encoder improvements do help.

The key architectural difference: SAM and SAM 2 are promptable—you can iteratively refine masks with additional clicks. FastSAM generates all masks in one shot, then you filter by prompts post-hoc. This fundamentally changes the interaction model.

Benchmark setup: 500 images, 3 prompt types, RTX 3090

I used the COCO 2017 validation set, randomly sampled 500 images with varying complexity (2-20 objects per image). Hardware: RTX 3090 (24GB), CUDA 11.8, PyTorch 2.0.1. All models ran in FP16 mixed precision.

For SAM and SAM 2, I used the vit_h checkpoint (largest variant). For FastSAM, the FastSAM-x model (the recommended one for quality). Preprocessing: resize to 1024×1024, normalize with ImageNet stats.

Three prompt scenarios:
1. Single point: one click per object (automatic everything mode)
2. Bounding box: ground-truth COCO boxes as prompts
3. Everything mode: generate all masks without prompts

Timing measured end-to-end: image load → preprocessing → inference → post-processing (NMS for FastSAM). I ran each image 10 times after a 5-image warmup and took the median.

Speed results: the 50x claim falls apart with preprocessing

FastSAM is 15.6x faster than SAM, not 50x. The difference? I included the image encoding step that most benchmarks conveniently skip. SAM’s ViT encoder takes ~3.8 seconds. The prompt decoder adds only ~60ms per prompt. If you’re doing interactive segmentation with multiple prompts on the same image, you encode once and decode multiple times—so the amortized cost drops significantly.

SAM 2 is 1.78x faster than SAM. The speedup comes from:
– Optimized ViT attention (Flash Attention 2)
– Better CUDA kernels for the decoder
– Slightly smaller embedding dimension (same ViT-H backbone, but compression in the neck)

FastSAM’s consistency across prompt types is notable—it doesn’t actually use the prompts during inference. It generates all masks first (~247ms), then filters them based on your prompt in post-processing (~4ms). This makes it blazing fast for batch jobs but awkward for interactive use.

Memory-wise, FastSAM wins handily. SAM and SAM 2 keep the massive ViT encoder in VRAM the whole time. FastSAM’s YOLOv8 backbone is a fraction of the size.

Quality comparison: where FastSAM fails

I measured mean IoU against COCO ground truth masks for 100 images with manually verified annotations. SAM’s whole pitch is “zero-shot segmentation,” so I didn’t fine-tune anything.

Mean IoU (higher is better):
– SAM: 0.847
– SAM 2: 0.851 (barely better, within noise)
– FastSAM: 0.661

That’s a 22% quality drop for FastSAM. The gap is even worse on small objects (<32×32 pixels). SAM’s ViT encoder captures fine details that FastSAM’s CNN backbone misses. On large, high-contrast objects (cars, people), FastSAM does fine—IoU ~0.78. On small stuff (utensils, jewelry, text), it drops to 0.41.

One specific failure case I noticed: SAM handles partial occlusion well. If you click on a person’s visible shoulder behind a pole, SAM correctly segments just the visible parts. FastSAM often includes the occluded region or fragments the mask.

But here’s the counterargument: if you’re doing exploratory data labeling and plan to manually fix masks anyway, FastSAM’s speed might be worth the quality hit. You can segment 1000 images in the time SAM does 65.

Code: running the benchmark yourself

Here’s the SAM inference loop I used. One gotcha: the official SamPredictor API caches the image embedding, which is great for multiple prompts but misleading for benchmarks. I explicitly clear it each iteration.

import torch
import time
from segment_anything import sam_model_registry, SamPredictor
import numpy as np

# Load SAM (ViT-H checkpoint, ~2.4GB download)
sam_checkpoint = "sam_vit_h_4b8939.pth"
device = "cuda"
sam = sam_model_registry["vit_h"](checkpoint=sam_checkpoint)
sam.to(device=device)
predictor = SamPredictor(sam)

# Dummy image (1024x1024x3)
image = np.random.randint(0, 255, (1024, 1024, 3), dtype=np.uint8)

# Warmup
for _ in range(5):
    predictor.set_image(image)
    masks, _, _ = predictor.predict(point_coords=np.array([[512, 512]]), point_labels=np.array([1]))
    predictor.reset_image()  # Critical: clear embedding cache

# Benchmark
timings = []
for _ in range(10):
    start = time.perf_counter()
    predictor.set_image(image)  # Encoder runs here (~3.8s)
    masks, scores, logits = predictor.predict(
        point_coords=np.array([[512, 512]]),
        point_labels=np.array([1])
    )
    end = time.perf_counter()
    timings.append((end - start) * 1000)  # Convert to ms
    predictor.reset_image()

print(f"SAM median: {np.median(timings):.1f}ms")
# Output: SAM median: 3912.3ms

FastSAM is even simpler—standard YOLOv8 inference:

from ultralytics import YOLO
import time
import numpy as np

model = YOLO("FastSAM-x.pt")
image = np.random.randint(0, 255, (1024, 1024, 3), dtype=np.uint8)

# Warmup
for _ in range(5):
    results = model(image, device="cuda", retina_masks=True, imgsz=1024, conf=0.4, iou=0.9)

# Benchmark
timings = []
for _ in range(10):
    start = time.perf_counter()
    results = model(image, device="cuda", retina_masks=True, imgsz=1024, conf=0.4, iou=0.9)
    end = time.perf_counter()
    timings.append((end - start) * 1000)

print(f"FastSAM median: {np.median(timings):.1f}ms")
# Output: FastSAM median: 247.2ms

One detail: retina_masks=True upsamples masks to full resolution (1024×1024). Without it, you get low-res masks (~160×160) that look blocky. This adds ~40ms but is mandatory for quality.

SAM 2’s API is nearly identical to SAM—just swap sam_model_registry["vit_h"] for build_sam2 from the official repo. I’m not entirely sure why SAM 2 is faster than SAM given they both use ViT-H; my best guess is Flash Attention 2 cuts ~30% off the encoder time, and some decoder optimizations save another 10%.

When to use each model

Use SAM if:
– Quality matters more than speed
– You need interactive refinement (add/remove points iteratively)
– Small objects or fine boundaries are critical
– You have GPU VRAM to spare (8GB+)

Use SAM 2 if:
– Same as SAM, but you’re willing to upgrade for 1.8x speedup
– You might extend to video later (SAM 2’s memory attention is built for tracking)
– You want slightly better mask quality on cluttered scenes

Use FastSAM if:
– Speed is the primary constraint (batch labeling, real-time apps)
– Objects are large and high-contrast
– You’re okay manually fixing 20-30% of masks
– Running on edge devices with limited VRAM (<4GB)

One use case where FastSAM genuinely shines: video pre-labeling. If you’re annotating a 10-minute video at 30fps (18,000 frames), SAM would take 19 hours. FastSAM finishes in 74 minutes. You’ll spend another hour fixing mistakes, but that’s still a 10x productivity win.

The memory attention trick in SAM 2 (and why it doesn’t help here)

SAM 2 introduces a memory bank $M_t$ that stores features from previous frames:

$$M_t = \{f_{t-k}, f_{t-k+1}, \dots, f_{t-1}\}$$

When segmenting frame $t$, the decoder attends to both the current embedding $E_t$ and the memory $M_t$:

$$\text{Attention}(Q, K, V) = \text{softmax}\left(\frac{QK^T}{\sqrt{d_k}}\right)V$$

where $K$ and $V$ are concatenated from $E_t$ and $M_t$. This helps with occlusion and temporal consistency—if an object disappears behind something, the decoder can “remember” its shape from earlier frames.

For single images, the memory is empty, so SAM 2 degenerates to SAM with a slightly different decoder. The 1.8x speedup comes from engineering (better CUDA kernels), not architecture.

If you’re doing video segmentation, SAM 2 is the obvious choice. For static images, the benefit is marginal.

Preprocessing pitfalls that skew benchmarks

Most SAM speed comparisons I’ve seen online make one of these mistakes:

1. Skipping the encoder step: They pre-compute embeddings, then only time the decoder. This inflates FastSAM’s advantage because SAM’s decoder is already fast (~60ms).
2. Using different image sizes: SAM’s ViT encoder scales quadratically with resolution. At 512×512, it’s ~4x faster than at 1024×1024. FastSAM is less sensitive (YOLOv8 uses a FPN, which handles multi-scale better).
3. Not warming up the GPU: The first inference is always slower due to CUDA kernel compilation. Without warmup, SAM looks 20-30% slower than it actually is.

One surprise I hit: SAM expects RGB input, but OpenCV loads images as BGR. I forgot to convert on the first run and got masks that were offset by ~5 pixels. The model didn’t crash—it just quietly gave wrong results. Always check your color space.

Another gotcha: SAM’s output masks are boolean numpy arrays (shape [1, H, W]), but FastSAM returns a list of Ultralytics Results objects. Extracting the actual masks requires results[0].masks.data.cpu().numpy(). I spent 20 minutes debugging a shape mismatch before realizing this.

Model checkpoint sizes and VRAM requirements

• SAM ViT-H: 2.4GB checkpoint, 8.2GB VRAM at FP16 (11.3GB at FP32)
• SAM 2: 2.6GB checkpoint, 7.6GB VRAM at FP16
• FastSAM-x: 138MB checkpoint, 3.1GB VRAM at FP16

SAM’s encoder is 632M parameters. The decoder is only 4M. The checkpoint is huge because the encoder dominates. FastSAM’s YOLOv8-x backbone is 68M parameters total—almost 10x smaller.

If you’re deploying to edge devices (Jetson, Coral), SAM is a non-starter. Even the smallest SAM variant (ViT-B, 91M encoder params) needs 4GB VRAM. FastSAM runs comfortably on a Jetson Nano (4GB VRAM) at ~15 FPS for 640×640 input.

One workaround I haven’t tested: quantizing SAM to INT8. In theory, this could cut VRAM by 4x, but ViT models are notoriously sensitive to quantization. I’d expect a 5-10% quality drop, which might defeat the purpose.

What I’d actually use in production

For a human-in-the-loop labeling tool, I’d use SAM 2. The interactive refinement is invaluable—users can click 2-3 times to fix a mask in 10 seconds, versus manually drawing polygons for 2 minutes. The 2-second latency is annoying but tolerable. I’d add a loading spinner and maybe pre-encode popular images on upload.

For a batch job (e.g., pre-labeling 100K images for review), I’d use FastSAM and budget time for manual fixes. At 247ms per image, you can process 14,500 images per hour on a single GPU. Even if 25% need fixing, that’s still faster than manual annotation.

For real-time applications (AR, robotics), neither is quite fast enough. FastSAM at 247ms is ~4 FPS. You’d need to drop to 640×640 input (gets you to ~8 FPS) or switch to a lighter YOLO variant (FastSAM-s hits 15 FPS but quality drops further).

And if you’re debugging any of these models at 2am, Dark Chocolate Espresso Beans are mandatory. Vision Transformers do not respect your sleep schedule.

FAQ

Q: Can I use SAM’s encoder once and run FastSAM’s decoder for speed?

No—they’re not architecturally compatible. SAM’s encoder outputs a dense 256-channel embedding. FastSAM’s “encoder” is a YOLOv8 backbone that outputs multi-scale feature maps (80, 40, 20 resolution). You can’t swap them. If you want a hybrid, you’d have to retrain from scratch, which defeats the purpose.

Q: Does SAM 2’s video memory help with multi-object tracking?

Yes, but only if you’re actually doing video. For tracking across frames, SAM 2’s memory attention significantly improves consistency—objects keep the same mask ID even under occlusion. For single images, it’s overkill. The original SAM is fine.

Q: Why is FastSAM so bad at small objects?

YOLOv8’s architecture downsamples aggressively (stride 32 in the deepest layer). A 16×16 object becomes a single pixel in the feature map. SAM’s ViT uses patch size 16 but maintains full spatial resolution through the encoder, so it preserves fine details. This is the fundamental CNN vs Transformer trade-off—CNNs are fast, Transformers are detailed.

What I’m still unsure about

I haven’t tested SAM or FastSAM on domain-shifted data (medical images, satellite imagery, infrared). The COCO benchmark is great for everyday objects, but both models were trained on natural images. I’d guess SAM’s zero-shot ability generalizes better, but FastSAM might close the gap if you fine-tune it. Someone should run this experiment.

Also unclear: how much of SAM 2’s speedup is from better CUDA kernels versus actual architectural improvements? If I backported Flash Attention 2 to the original SAM, would it match SAM 2’s speed? The paper doesn’t break this down, and I don’t have time to reimplement it.

For now, I’m sticking with SAM 2 for quality-critical work and FastSAM for batch jobs. If you need sub-100ms latency, neither is the answer—you’re looking at MobileSAM or a fully custom CNN-based segmenter. But for the 80% of use cases where 200-2000ms is acceptable, this shootout should give you the numbers to decide.
